Coriolis Flow Meters

Flow meters GKS FC series – coriolis mass flow meter of liquids and gases.

Contact us
Coriolis Flow Meters

Accuracy and efficiency has become a constant factor in many industries, especially in commercial oil and gas metering.

Flow meters GKS FC series-coriolis mass flow meter of liquids and gases.

Designed for use in a variety of industries, including:

  • Chemical;
  • Oil-gas;
  • Nutritional;
  • Pharmaceutical.

GCS FC series flowmeters are designed for optimal operation in hazardous areas and have many certificates and tolerances.

Main advantage:

  • High accuracy (accuracy class 0,1%)
  • Flexible installation due to compact design
  • HART interface
  • Easy setup, Plug&Play function
  • Resistance to environmental influences and the measured environment

Measured parameters:

  • Mass and volume flow
  • Densities
  • The temperature of the process environment
  • The corrected volumetric flow
  • Initial density
  • Component a consumption
  • The flow of component B
  • % of component A
  • % component B
Technical specification
Transducer
Execution Compact or spaced
Communication tools HART, USB
Transducer material Aluminum with corrosion resistant coating
Degree of protection IP67
Inputs/outputs Up to 4 channels of combined analog, relay or discrete outputs and discrete input
Local indication LCD display, 240×160 pixels
Power 24-90 V DC, 100-240 V AC
Sensor
Sizes DN15 DN25 DN50 DN80
Accuracy class 0,1%
Stability 0,05%
Flow range 3700 11500 52000 136000
Weight 4,6 7,9 15 50
Material Wetted parts: stainless steel 316L, stainless steel body 304
Nominal pressure 100 bar
Enclosure protection IP67
Rated temperature -50…200 °С
Ambient temperature -40…60 °С
